What Is a Jig Concentrator & How Does It Work?

A jig concentrator, also known as a jig machine, is a high-efficiency gravity separation device widely applied in mineral processing and metal recovery industries. Designed to separate valuable minerals or metals from gangue materials based on density differences, it is a core piece of equipment for ore dressing and waste metal recycling projects.

Ruijie jig concentrators offer flexible customization to meet diverse processing needs. Classified by processing area, they are available in 1 m², 2 m², 4 m², and 8 m² models, suitable for small-scale workshops and large-scale industrial plants respectively. In terms of structural design, they can be divided into single-chamber, double-chamber, and triple-chamber types, allowing operators to adjust the separation process according to material characteristics.

Using a jig concentrator is straightforward with standardized operational steps. First, select the appropriate model and chamber type based on the particle size and density of the raw materials. Then, feed the materials evenly into the jig chamber. The machine generates high, stable, and powerful vibration to stratify the materials: dense metals sink to the bottom, while light gangue floats upward. Finally, collect the separated metals from the discharge port. A standout design feature of Ruijie's jig concentrators is the movable top screen frame, which can be easily disassembled and cleaned, reducing downtime and improving operational efficiency.

The advantages of Ruijie jig concentrators are evident in performance and durability. Its high-stability vibration system ensures more efficient metal recovery, maximizing the utilization of valuable resources for users. Additionally, the equipment adopts high wear-resistant plates, which enhance structural stability and extend service life, significantly lowering long-term maintenance costs.

As a reliable gravity separation solution, Ruijie jig concentrators balance efficiency, durability, and ease of use, making them an ideal choice for metal recovery and mineral processing projects.
