Security Controller Fire Alarm Fire Fighting Automatic Security Systems

Quantity : 1000

255-1020 points 1 loop to 4 loops LPCB approval addressable fire alarm system. Commercial and industry fire security equipment. Professional fire alarm system.

Intelligent bus control mode: max 255 addressable points per loop,max 4 loops,max 48 zones

Loop card type design: 1-4 loop cards can be selected

Glass fuse per loop

Black box function

Self-design loop protocol

Wall-mounted structure,compac and exquisite

Akzo outer coating;anti-corrosion

Language: simplified Chinese,Enlish,Turkish and Russian(cus to mized).Self-design loop protocol

TECHNICAL SPECIFICATIONS
Volate AC230V(50HZ), Voltage range: +10%--15%
Current 1A
Outputs Fire output .Fault output .24V power output .Loop output
Capacity 1020/4 loops addressable points
LCD screen size 7-inch color LCD screen
Standby bettery 12V/12AH sealed lead acid battery*2
Dimension(L*W*H) 420mm×140mm×560mm
Operating environment Temperature: -5℃-+50℃: Relative Humidity: ≤95%non- condensing
Communication interface RS485、CAN、USB

DETAILS
The control panel is mounted on the wall through 4 mounting holes, the dimensions of the mounting holes are shown in the picture.
The right side of the control panel has 8 wiring holes, which are easy for wiring between the control panel and field devices.
There are also 5 knock holes at the top, if the holes on the right side are not enough.

Location : 348 St., 53784 AU,
Contact : Sarah Huang, +8618050996636

Good deal: buying from seller

Visit our guide for a secure transaction! Under no circumstances Algomtl can be held responsible for the content of the ads published. Only the sellers and buyers responsability is involved in case of dispute.
We invite you to read our terms of use. You can also visit our FAQ section and see our information section on the risks associated with counterfeiting.
